welded wire mesh can be classified into electro galvanized welded wire mesh , hot-dipped galvanized welded wire mesh . It is super in corrosion resistance with Precise spot welding,Strong structure,Flat surface and Beautiful looks.
Welded wire mesh can be processed into animal cages, such as birds cage,chicken cage,rabbit cage,mink cage,parrot cage,dog cage etc.
Material:
low carbon steel wire, black iron wire,electro galvanized wire, hot dipped galvanized wire,stainless steel wire, aluminum wire
Width: 0.5m-2.0m
We can supply in rolls and in panels. The length and width as clients’ requirements.
Surface treatment:
Hot dipped galvanized before welding
Hot dipped galvanized after welding
Electro galvanized before welding
Electro galvanized after welding
PVC coating after welding
Welded Wire Mesh Features
· Welded Wire Mesh is made of high quality stainless or steel wire.
· Welded Wire Mesh has various configurations and sizes.
· Used for the loose strata to avoid falling rocks.
· Suitable for shotcrete applications
· Range of sizes to suit roadway width and bolting patterns.
· Easy installation
· Available in black or hot dip galvanized
Processing:
1) Welded wire mesh electro or hot dipped galvanized after welding
2) Welded wire mesh electro or hot dipped galvanized before welding
3) Welded wire mesh in PVC coated
4) Welded wire mesh in stainless steel
Welded Wire Mesh Application
Welded wire mesh is used in industry and agriculture building, Transportation and mining for all such purposes as poultry houses, Egg baskets, Runway enclosures, Draining rack, Fruit drying screen, Fence, Mink Cages.
Specifications:
| Standard welded wire mesh | ||||
| Opening size | Wire diameter(BWG) | |||
| In inch | In mm | |||
| 1/4''×1/4'' | 6.4mm×6.4mm | 22 23 24 | ||
| 3/8"×3/8" | 10.6mm×10.6mm | 19 20 21 22 | ||
| 1/2"×1/2" | 12.7mm×12.7mm | 16 17 18 19 20 21 22 23 | ||
| 5/8"×5/8" | 16mm×16mm | 18 19 20 21 | ||
| 3/4"×3/4" | 19.1mm×19.1mm | 16 17 18 19 20 21 | ||
| 1"× 1/2" | 25.4mm×12.7mm | 16 17 18 19 20 21 | ||
| 1-1/2"×1-1/2" | 38mm×38mm | 14 15 16 17 18 19 | ||
| 1"×2" | 25.4mm×50.8mm | 14 15 16 | ||
| 2"×2" | 50.8mm×50.8mm | 12 13 14 15 16 | ||
| Technical note: Standard roll length:20m/25m/30m width:0.5m-2.0m width:0.5m-2.0m Special size available at request Packing:waterproof paper inside,plastic film outside or as client’s requirements. | ||||
| Galvanized Fencing Mesh | ||||
| Opening size | Wire diameter(mm) | |||
| In inch | In mm | |||
| 2"'×3" | 50mm×75mm | 2.0mm 2.5mm 1.65mm | ||
| 3"×3" | 75mm×75mm | 2.67mm 2.41mm 2.11mm 1.83mm1.65mm | ||
| 2"'×4" | 50mm×100mm | 2.11mm 2.5mm | ||
| 4"'×4" | 100mm×100mm | 2.0mm 2.5mm | ||
| Technical note: Standard roll length:20m/25m/30m width:0.5m-2.0m width:0.5m-2.0m Special size available at request Packing:waterproof paper inside,plastic film outside or as client’s requirements. | ||||
